Entering the category of large excavators, the AQ-5 hydraulic drum cutter is an excellent option for carriers in the 50-80 ton weight class. The combination of power, and robust design of the transmission and cutting drums, the AQ-5 is capable of cutting many types of hard rock with excellent efficiency.
Recommended excavators/carrier size class: 50-80 tons
Hydraulic Power: 270HP (200kW)
| Technical Data | Unit | AQ-5 |
|---|---|---|
| Cutting Head Diameter (B) | in (mm) | 33 (840) |
| Cutting Head Width (A) | in (mm) | 53 (1.345) |
| Oil Flow | gpm (l/min) | 95-160 (360-610) |
| Max Pressure | psi (bar) | 5,800 (400) |
| Max Torque | ft lbs (Nm) | 39,310 (53.300) |
| Max Cutting Force | lbs (N) | 28,686 (127.655) |
| Operating Weight | lbs (kg) | 7,832 (3.560) |
Please note hydraulic power rating should not be exceeded
Quantity of cutter bits for standard drums: 64
